voc 催化燃烧设备工作原理，在化学反应过程中，利用催化剂降低燃烧温度，加速有毒有害气体氧化的方法，叫做催化燃烧法。由于催化剂的载体是由多孔材料制作的，具有较大的比表面积和合适的孔径，当加热到 3 。。一 45 。’ C 的有机气体通过催化层时，氧和有机气体被吸附在多孔材料表层的催化剂上，增加了氧和有机气体接触碰撞的机会，提高了活性，使有机气体与氧产生剧烈的化学反应而生成 C02 和 H20 ，同时产生热量，从而使得有机气体变成无害气体。
VOC catalytic combustion equipment working principle, in the chemical reaction process, the use of catalyst to reduce combustion temperature, accelerate the oxidation of toxic and harmful gases, is called catalytic combustion method. As the support of the catalyst is made of porous materials, it has a large specific surface area and suitable pore size.. 45. " When the organic gas of C passes through the catalytic layer, oxygen and organic gas are adsorbed on the catalyst on the surface of porous materials, which increases the chance of contact and collision between oxygen and organic gas, improves the activity, and makes the organic gas and oxygen produce violent chemical reaction to produce CO2 and H20, and at the same time generates heat, so that the organic gas becomes harmless gas.
与热力燃烧法相比，催化燃烧所需的辅助燃料少能量消耗低，化剂的中毒、设备设施的体积小。但是，由于使用的催催化床层的换和清洁费用高等问题，影响了这种方法在工业生产过程中的推广和应币。
Compared with the thermal combustion method, catalytic combustion needs less auxiliary fuel, lower energy consumption, chemical poisoning and small volume of equipment and facilities. However, due to the high cost of catalyst bed replacement and cleaning, the popularization and application of this method in industrial production process are affected.

voc 催化燃烧设备是利用催化剂使有机废气在较低的起燃温度下进行没有火焰的燃烧以达到氧化分解的净化装置。催化燃烧设备的结构一般由阻火过滤器、换热器、预热室、热电阻、催化床和防暴器组成，电控系统由 PLC 控制器、文本显示器、变频调速器、点火器、紫外线传感器、热电偶等电控设备，另外还有风机以及调节燃气与空气比例的零压阀组成．
VOC catalytic combustion equipment is a kind of purification device which uses catalyst to make organic waste gas burn without flame at low ignition temperature to achieve oxidation and decomposition. The structure of catalytic combustion equipment is generally composed of fire-retardant filter, heat exchanger, preheating chamber, thermal resistance, catalytic bed and anti riot device. The electronic control system consists of PLC controller, text display, frequency converter, ignitor, ultraviolet sensor, thermocouple and other electrical control equipment. In addition, there are fans and zero pressure valves to adjust the proportion of gas and air
RCO 催化燃烧设备内设加热室，启动加热装置，进入内部循环，当热气源达到有机物的沸点时，有机物从活性炭内跑出来，进入催化室进行催化分解成 C02 和 H20 ，同时释放出能量。利用释放出的能量再进入吸附床脱附时，此时加热装置停止工作，有机废气在催化燃烧室内维持自燃，尾气，循环进行，直至有机物从活性炭内部分离，至催化室分解。
The RCO catalytic combustion equipment is equipped with a heating chamber, which starts the heating device and enters the internal circulation. When the hot gas source reaches the boiling point of the organic matter, the organic matter will run out of the activated carbon and enter the catalytic chamber for catalytic decomposition into C02 and H20, and release energy at the same time. When the released energy enters the adsorption bed for desorption, the heating device stops working, and the organic waste gas maintains spontaneous combustion in the catalytic combustion chamber, and the tail gas circulates until the organic matter is separated from the activated carbon and decomposed in the catalytic chamber.
越华润华告诉大家voc催化燃烧设备是如何进行环保创献的？大家在购买的过程中一定要根据自我的需求来考量！
Yuehua Runhua tells you how VOC catalytic combustion equipment makes environmental contribution? Everyone in the purchase process must be based on their own needs to consider!
